PCSF51
Things Embedded are an official DFI UK distributor and can supply the PCSF51 fully configured and imaged.
Available in 3 Variants
| Overview |
|---|
| Brand & Model |
| Performance |
| Memory Capacity |
| Operating Software |
| Processor |
| Processor Series |
| Processor Models |
| Memory |
| BIOS |
| Secure Crypto Processor |
| Operating System |
| Graphics |
| Integrated GPU |
| Graphics Family |
| 4K Support |
| Display Outputs |
| Display Port Type |
| I/O |
| Ethernet |
| Ethernet Connector Type |
| Ethernet Speed |
| USB |
| USB Connector Type |
| USB Generation |
| Digital I/O |
| Expansion |
| M.2 |
| M.2 Key Support |
| M.2 Signal Support |
| M.2 Slot Size |
| Wireless Connectivity |
| Connectivity |
| Storage |
| Number of Storage Bays |
| Storage Interface |
| Storage |
| Power |
| Power Input |
| Environmental Conditions |
| Thermal Dissipation |
| Thermal Dissipation |
| Operating Temperature |
| Operating Temperature |
| Storage Temperature |
| Humidity |
| Certification |
| Mechanical Properties |
| Dimensions |
| DFI PCSF51-BN-46R232 |
| 1.8" Industrial Dual Core Ryzen SBC with R2312 CPU |
| 8GB |
|
Linux Windows |
|
AMD Ryzen R2000 |
| R2000 |
| R2312 |
| 8GB Soldered On-board |
| AMD SPI |
| TPM 2.0 (Trusted Platform Module) |
|
Linux Ubuntu 20.04 Windows 10 Windows 11 |
| AMD Radeon Series |
| AMD Radeon Graphics |
| 4K Display Support |
| 1x HDMI |
| HDMI |
| 1x Ethernet Ports |
| RJ45 |
| 1 x GbE LAN [RJ45] |
| GbE |
| 1x USB Ports |
| Type A |
| USB3 |
| 1 x USB 3.1 Gen 1 [Type A] |
| DIO [8-lines] |
| 1x M.2 Expansion Slots |
| 1x M.2 E-Key [PCIe x1/USB 2.0] [2230] |
| E-Key |
|
PCIe USB |
| 2230 |
| Optional WiFi/Bluetooth |
| Wireless |
| 1 |
| eMMC |
| 128GB eMMC |
| 12V DC [Terminal Block] |
|
Optional Heat Spreader Optional Heatsink |
|
Heat Spreader Heatsink |
| 0°C to 60°C [32°F to 147°F] |
| Standard Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 5% - 90% (Non-condensing) |
|
CE FCC UKCA |
| 84mm x 55mm (3.31" x 2.17") |
| DFI PCSF51-BN-46R234 |
| Industrial 1.8" Femto-ITX AMD Ryzen R2314 Quad Core Single Board Computer |
| 8GB |
|
Linux Windows |
|
AMD Ryzen R2000 |
| R2000 |
| R2314 |
| 8GB Soldered On-board |
| AMD SPI |
| TPM 2.0 (Trusted Platform Module) |
|
Linux Ubuntu 20.04 Windows 10 Windows 11 |
| AMD Radeon Series |
| AMD Radeon Graphics |
| 4K Display Support |
| 1x HDMI |
| HDMI |
| 1x Ethernet Ports |
| RJ45 |
| 1 x GbE LAN [RJ45] |
| GbE |
| 1x USB Ports |
| Type A |
| USB3 |
| 1 x USB 3.1 Gen 1 [Type A] |
| DIO [8-lines] |
| 1x M.2 Expansion Slots |
| 1x M.2 E-Key [PCIe x1/USB 2.0] [2230] |
| E-Key |
|
PCIe USB |
| 2230 |
| Optional WiFi/Bluetooth |
| Wireless |
| 1 |
| eMMC |
| 128GB eMMC |
| 12V DC [Terminal Block] |
|
Optional Heat Spreader Optional Heatsink |
|
Heat Spreader Heatsink |
| 0°C to 60°C [32°F to 147°F] |
| Standard Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 5% - 90% (Non-condensing) |
|
CE FCC UKCA |
| 84mm x 55mm (3.31" x 2.17") |
| DFI PCSF51-BN-46R254 |
| Industrial Femto-ITX 1.8" AMD Ryzen R2514 Quad Core SBC |
| 8GB |
|
Linux Windows |
|
AMD Ryzen R2000 |
| R2000 |
| R2514 |
| 8GB Soldered On-board |
| AMD SPI |
| TPM 2.0 (Trusted Platform Module) |
|
Linux Ubuntu 20.04 Windows 10 Windows 11 |
| AMD Radeon Series |
| AMD Radeon Graphics |
| 4K Display Support |
| 1x HDMI |
| HDMI |
| 1x Ethernet Ports |
| RJ45 |
| 1 x GbE LAN [RJ45] |
| GbE |
| 1x USB Ports |
| Type A |
| USB3 |
| 1 x USB 3.1 Gen 1 [Type A] |
| DIO [8-lines] |
| 1x M.2 Expansion Slots |
| 1x M.2 E-Key [PCIe x1/USB 2.0] [2230] |
| E-Key |
|
PCIe USB |
| 2230 |
| Optional WiFi/Bluetooth |
| Wireless |
| 1 |
| eMMC |
| 128GB eMMC |
| 12V DC [Terminal Block] |
|
Optional Heat Spreader Optional Heatsink |
|
Heat Spreader Heatsink |
| 0°C to 60°C [32°F to 147°F] |
| Standard Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 5% - 90% (Non-condensing) |
|
CE FCC UKCA |
| 84mm x 55mm (3.31" x 2.17") |
