GH551
Things Embedded are an official DFI UK distributor and can supply the GH551 fully configured and imaged.
- Select Variant GH551
-
GH551-BC1-R2312
GH551 with AMD Ryzen R2312 Processor, -5C to 65C -
GH551-BC1-R2314
GH551 with AMD Ryzen R2314 Processor, -5C to 65C -
GH551-BC1-R2514
GH551 with AMD Ryzen R2514 Processor, -5C to 65C -
GH551-EC1-R1606G
GH551 with AMD Ryzen R1606G Processor, -30C to 80C -
GH551-EC1-V1605B
GH551 with AMD Ryzen V1605B Processor, -30C to 80C -
GH551-BC1-R1505G
GH551 with AMD Ryzen R1505G Processor, -5C to 65C -
GH551-BC1-R1606G
GH551 with AMD Ryzen R1606G Processor, -5C to 65C -
GH551-EC1-V1404I
GH551 with AMD Ryzen V1404I Processor, -30C to 80C -
GH551-BC1-V1202B
GH551 with AMD Ryzen V1202B Processor, -5C to 65C -
GH551-BC1-V1605B
GH551 with AMD Ryzen V1605B Processor, -5C to 65C
Available in 10 Variants
| Overview |
|---|
| Brand & Model |
| Performance |
| Memory Capacity |
| Memory Slots |
| Memory Type |
| ECC Memory Support |
| Operating Software |
| Processor |
| Processor Series |
| Processor Models |
| Memory |
| BIOS |
| Secure Crypto Processor |
| Operating System |
| Graphics |
| Integrated GPU |
| Graphics Family |
| Multi Display Support |
| Display Outputs |
| Display Port Type |
| Audio |
| Interface |
| I/O |
| Ethernet |
| Ethernet Connector Type |
| Ethernet Speed |
| USB |
| USB Connector Type |
| USB Generation |
| Serial |
| Serial Connector Type |
| Serial Protocol |
| Digital I/O |
| Expansion |
| M.2 |
| M.2 Key Support |
| M.2 Signal Support |
| M.2 Slot Size |
| mPCIe |
| mPCIe Support |
| mPCIe Slot Size |
| SIM Slots |
| Wireless Connectivity |
| Connectivity |
| Storage |
| Number of Storage Bays |
| Storage Interface |
| Storage |
| NVMe |
| Power |
| Power Input |
| Environmental Conditions |
| Thermal Dissipation |
| Thermal Dissipation |
| Operating Temperature |
| Operating Temperature |
| Storage Temperature |
| Humidity |
| Certification |
| Mechanical Properties |
| Weight |
| Dimensions |
| DFI GH551-BC1-R2312 |
| AMD Ryzen 3.5" Single Board Computer with LVDS |
| 16GB |
| 1 |
| DDR4 |
| Supports ECC Memory |
|
Linux Windows |
|
AMD Ryzen R-Series |
| R-Series |
| R2312 |
| 1x DDR4 3200MHz SO-DIMM Slot, 16GB |
| AMI |
| TPM 2.0 (Trusted Platform Module) |
|
Linux Windows 10 |
| AMD Radeon Series |
| AMD Radeon Graphics |
| Triple Display Support |
|
1x LVDS 2x Display Port |
|
Display Port LVDS |
|
Line-Out Mic-In |
| 3x Ethernet Ports |
| RJ45 |
| 3 x GbE LAN [RJ45] |
| GbE |
| 4x USB Ports |
|
Board Connectors Type A |
|
USB2 USB3 |
|
1 x USB 2.0 [Board] 1 x USB 2.0 [Type A] 2 x USB 3.1 Gen 1 [Type A] |
| 1x Serial Ports |
| Board Connectors |
|
RS-232 RS-422 RS-485 |
| 1 x RS232/422/485 [Board] |
| DIO [8-lines] |
| 1x M.2 Expansion Slots |
| 1x M.2 M-Key [PCIe x4] [2242/2280] |
| M-Key |
| PCIe |
|
2242 2280 |
| 1x mPCIe Slots |
| 1 x mPCIe [PCIe/USB] |
|
PCIe USB |
| Full-Size |
| 1x SIM Slots |
|
Optional 4G Modem Optional 5G Modem Optional WiFi/Bluetooth |
|
4G 5G Wireless |
| 2 |
|
M.2 SSD SATA Port |
|
1x M.2 SSD 1x SATA Port |
| NVMe SSD Support |
| 12V DC [4-Pin] |
|
Optional Heat Spreader Optional Heatsink |
|
Heat Spreader Heatsink |
| -5°C to 65°C [23°F to 149°F] |
| Wide Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 10-90% (Non-condensing) |
|
CE FCC RoHS |
| 0.2 Kg (0.44 Lbs) |
| 146mm x 102mm (5.75" x 4.02") |
| DFI GH551-BC1-R2314 |
| AMD Ryzen 3.5 Inch SBC with R2314 CPU |
| 16GB |
| 1 |
| DDR4 |
| Supports ECC Memory |
|
Linux Windows |
|
AMD Ryzen R-Series |
| R-Series |
| R2314 |
| 1x DDR4 3200MHz SO-DIMM Slot, 16GB |
| AMI |
| TPM 2.0 (Trusted Platform Module) |
|
Linux Windows 10 |
| AMD Radeon Series |
| AMD Radeon Graphics |
| Triple Display Support |
|
1x LVDS 3x Display Port |
|
Display Port LVDS |
|
Line-Out Mic-In |
| 3x Ethernet Ports |
| RJ45 |
| 3 x GbE LAN [RJ45] |
| GbE |
| 4x USB Ports |
|
Board Connectors Type A |
|
USB2 USB3 |
|
1 x USB 2.0 [Board] 1 x USB 2.0 [Type A] 2 x USB 3.1 Gen 1 [Type A] |
| 1x Serial Ports |
| Board Connectors |
|
RS-232 RS-422 RS-485 |
| 1 x RS232/422/485 [Board] |
| DIO [8-lines] |
| 1x M.2 Expansion Slots |
| 1x M.2 M-Key [PCIe x4] [2242/2280] |
| M-Key |
| PCIe |
|
2242 2280 |
| 1x mPCIe Slots |
| 1 x mPCIe [PCIe/USB] |
|
PCIe USB |
| Full-Size |
| 1x SIM Slots |
|
Optional 4G Modem Optional 5G Modem Optional WiFi/Bluetooth |
|
4G 5G Wireless |
| 2 |
|
M.2 SSD SATA Port |
|
1x M.2 SSD 1x SATA Port |
| NVMe SSD Support |
| 12V DC [4-Pin] |
|
Optional Heat Spreader Optional Heatsink |
|
Heat Spreader Heatsink |
| -5°C to 65°C [23°F to 149°F] |
| Wide Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 10-90% (Non-condensing) |
|
CE FCC RoHS |
| 0.2 Kg (0.44 Lbs) |
| 146mm x 102mm (5.75" x 4.02") |
| DFI GH551-BC1-R2514 |
| 12V AMD Ryzen Embedded R2514 Single Board Computer |
| 16GB |
| 1 |
| DDR4 |
| Supports ECC Memory |
|
Linux Windows |
|
AMD Ryzen R-Series |
| R-Series |
| R2514 |
| 1x DDR4 3200MHz SO-DIMM Slot, 16GB |
| AMI |
| TPM 2.0 (Trusted Platform Module) |
|
Linux Windows 10 |
| AMD Radeon Series |
| AMD Radeon Graphics |
| Triple Display Support |
| 4x Display Ports |
| Display Port |
|
Line-Out Mic-In |
| 3x Ethernet Ports |
| RJ45 |
| 3 x GbE LAN [RJ45] |
| GbE |
| 4x USB Ports |
|
Board Connectors Type A |
|
USB2 USB3 |
|
1 x USB 2.0 [Board] 1 x USB 2.0 [Type A] 2 x USB 3.1 Gen 1 [Type A] |
| 1x Serial Ports |
| Board Connectors |
|
RS-232 RS-422 RS-485 |
| 1 x RS232/422/485 [Board] |
| DIO [8-lines] |
| 1x M.2 Expansion Slots |
| 1x M.2 M-Key [PCIe x4] [2242/2280] |
| M-Key |
| PCIe |
|
2242 2280 |
| 1x mPCIe Slots |
| 1 x mPCIe [PCIe/USB] |
|
PCIe USB |
| Full-Size |
| 1x SIM Slots |
|
Optional 4G Modem Optional 5G Modem Optional WiFi/Bluetooth |
|
4G 5G Wireless |
| 2 |
|
M.2 SSD SATA Port |
|
1x M.2 SSD 1x SATA Port |
| NVMe SSD Support |
| 12V DC [4-Pin] |
|
Optional Heat Spreader Optional Heatsink |
|
Heat Spreader Heatsink |
| -5°C to 65°C [23°F to 149°F] |
| Wide Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 10-90% (Non-condensing) |
|
CE FCC RoHS |
| 0.2 Kg (0.44 Lbs) |
| 146mm x 102mm (5.75" x 4.02") |
| DFI GH551-EC1-R1606G |
| 3.5" Ryzen Embedded R1606F SBC with USB3 and RS232/422/485 Serial |
| 16GB |
| 1 |
| DDR4 |
| Supports ECC Memory |
|
Linux Windows |
|
AMD Ryzen R-Series |
| R-Series |
| R1606G |
| 1x DDR4 3200MHz SO-DIMM Slot, 16GB |
| AMI |
| TPM 2.0 (Trusted Platform Module) |
|
Linux Windows 10 |
| AMD Radeon Series |
| AMD Radeon Graphics |
| Triple Display Support |
| 3x Display Port |
| Display Port |
|
Line-Out Mic-In |
| 3x Ethernet Ports |
| RJ45 |
| 3 x GbE LAN [RJ45] |
| GbE |
| 4x USB Ports |
|
Board Connectors Type A |
|
USB2 USB3 |
|
1 x USB 2.0 [Board] 1 x USB 2.0 [Type A] 2 x USB 3.1 Gen 1 [Type A] |
| 1x Serial Ports |
| Board Connectors |
|
RS-232 RS-422 RS-485 |
| 1 x RS232/422/485 [Board] |
| DIO [8-lines] |
| 1x M.2 Expansion Slots |
| 1x M.2 M-Key [PCIe x4] [2242/2280] |
| M-Key |
| PCIe |
|
2242 2280 |
| 1x mPCIe Slots |
| 1 x mPCIe [PCIe/USB] |
|
PCIe USB |
| Full-Size |
| 1x SIM Slots |
|
Optional 4G Modem Optional 5G Modem Optional WiFi/Bluetooth |
|
4G 5G Wireless |
| 2 |
|
M.2 SSD SATA Port |
|
1x M.2 SSD 1x SATA Port |
| NVMe SSD Support |
| 12V DC [4-Pin] |
|
Optional Heat Spreader Optional Heatsink |
|
Heat Spreader Heatsink |
| -30°C to 80°C [-22°F to 176°F] |
| Wide Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 10-90% (Non-condensing) |
|
CE FCC RoHS |
| 0.2 Kg (0.44 Lbs) |
| 146mm x 102mm (5.75" x 4.02") |
| DFI GH551-EC1-V1605B |
| 3.5 Inch AMD Ryzen Embedded V1605B Wide Temperature SBC |
| 16GB |
| 1 |
| DDR4 |
| Supports ECC Memory |
|
Linux Windows |
|
AMD Ryzen V-Series |
| V-Series |
| V1605B |
| 1x DDR4 3200MHz SO-DIMM Slot, 16GB |
| AMI |
| TPM 2.0 (Trusted Platform Module) |
|
Linux Windows 10 |
| AMD Radeon Series |
| AMD Radeon Graphics |
| Triple Display Support |
| 4x Display Ports |
| Display Port |
|
Line-Out Mic-In |
| 3x Ethernet Ports |
| RJ45 |
| 3 x GbE LAN [RJ45] |
| GbE |
| 4x USB Ports |
|
Board Connectors Type A |
|
USB2 USB3 |
|
1 x USB 2.0 [Board] 1 x USB 2.0 [Type A] 2 x USB 3.1 Gen 1 [Type A] |
| 1x Serial Ports |
| Board Connectors |
|
RS-232 RS-422 RS-485 |
| 1 x RS232/422/485 [Board] |
| DIO [8-lines] |
| 1x M.2 Expansion Slots |
| 1x M.2 M-Key [PCIe x4] [2242/2280] |
| M-Key |
| PCIe |
|
2242 2280 |
| 1x mPCIe Slots |
| 1 x mPCIe [PCIe/USB] |
|
PCIe USB |
| Full-Size |
| 1x SIM Slots |
|
Optional 4G Modem Optional 5G Modem Optional WiFi/Bluetooth |
|
4G 5G Wireless |
| 2 |
|
M.2 SSD SATA Port |
|
1x M.2 SSD 1x SATA Port |
| NVMe SSD Support |
| 12V DC [4-Pin] |
|
Optional Heat Spreader Optional Heatsink |
|
Heat Spreader Heatsink |
| -30°C to 80°C [-22°F to 176°F] |
| Wide Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 10-90% (Non-condensing) |
|
CE FCC RoHS |
| 0.2 Kg (0.44 Lbs) |
| 146mm x 102mm (5.75" x 4.02") |
| DFI GH551-BC1-R1505G |
| AMD Ryzen R1505G Biscuit SBC with 2x DP++ and LVDS |
| 16GB |
| 1 |
| DDR4 |
| Supports ECC Memory |
|
Linux Windows |
|
AMD Ryzen R-Series |
| R-Series |
| R1505G |
| 1x DDR4 3200MHz SO-DIMM Slot, 16GB |
| AMI |
| TPM 2.0 (Trusted Platform Module) |
|
Linux Windows 10 |
| AMD Radeon Series |
| AMD Radeon Graphics |
| Triple Display Support |
|
1x LVDS 2x Display Port |
|
Display Port LVDS |
|
Line-Out Mic-In |
| 3x Ethernet Ports |
| RJ45 |
| 3 x GbE LAN [RJ45] |
| GbE |
| 4x USB Ports |
|
Board Connectors Type A |
|
USB2 USB3 |
|
1 x USB 2.0 [Board] 1 x USB 2.0 [Type A] 2 x USB 3.1 Gen 1 [Type A] |
| 1x Serial Ports |
| Board Connectors |
|
RS-232 RS-422 RS-485 |
| 1 x RS232/422/485 [Board] |
| DIO [8-lines] |
| 1x M.2 Expansion Slots |
| 1x M.2 M-Key [PCIe x4] [2242/2280] |
| M-Key |
| PCIe |
|
2242 2280 |
| 1x mPCIe Slots |
| 1 x mPCIe [PCIe/USB] |
|
PCIe USB |
| Full-Size |
| 1x SIM Slots |
|
Optional 4G Modem Optional 5G Modem Optional WiFi/Bluetooth |
|
4G 5G Wireless |
| 2 |
|
M.2 SSD SATA Port |
|
1x M.2 SSD 1x SATA Port |
| NVMe SSD Support |
| 12V DC [4-Pin] |
|
Optional Heat Spreader Optional Heatsink |
|
Heat Spreader Heatsink |
| -5°C to 65°C [23°F to 149°F] |
| Wide Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 10-90% (Non-condensing) |
|
CE FCC RoHS |
| 0.2 Kg (0.44 Lbs) |
| 146mm x 102mm (5.75" x 4.02") |
| DFI GH551-BC1-R1606G |
| AMD Ryzen R1606G 3.5" Single Board Computer with Triple 4K Display |
| 16GB |
| 1 |
| DDR4 |
| Supports ECC Memory |
|
Linux Windows |
|
AMD Ryzen R-Series |
| R-Series |
| R1606G |
| 1x DDR4 3200MHz SO-DIMM Slot, 16GB |
| AMI |
| TPM 2.0 (Trusted Platform Module) |
|
Linux Windows 10 |
| AMD Radeon Series |
| AMD Radeon Graphics |
| Triple Display Support |
| 3x Display Port |
| Display Port |
|
Line-Out Mic-In |
| 3x Ethernet Ports |
| RJ45 |
| 3 x GbE LAN [RJ45] |
| GbE |
| 4x USB Ports |
|
Board Connectors Type A |
|
USB2 USB3 |
|
1 x USB 2.0 [Board] 1 x USB 2.0 [Type A] 2 x USB 3.1 Gen 1 [Type A] |
| 1x Serial Ports |
| Board Connectors |
|
RS-232 RS-422 RS-485 |
| 1 x RS232/422/485 [Board] |
| DIO [8-lines] |
| 1x M.2 Expansion Slots |
| 1x M.2 M-Key [PCIe x4] [2242/2280] |
| M-Key |
| PCIe |
|
2242 2280 |
| 1x mPCIe Slots |
| 1 x mPCIe [PCIe/USB] |
|
PCIe USB |
| Full-Size |
| 1x SIM Slots |
|
Optional 4G Modem Optional 5G Modem Optional WiFi/Bluetooth |
|
4G 5G Wireless |
| 2 |
|
M.2 SSD SATA Port |
|
1x M.2 SSD 1x SATA Port |
| NVMe SSD Support |
| 12V DC [4-Pin] |
|
Optional Heat Spreader Optional Heatsink |
|
Heat Spreader Heatsink |
| -5°C to 65°C [23°F to 149°F] |
| Wide Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 10-90% (Non-condensing) |
|
CE FCC RoHS |
| 0.2 Kg (0.44 Lbs) |
| 146mm x 102mm (5.75" x 4.02") |
| DFI GH551-EC1-V1404I |
| AMD Ryzen V1404I Wide Temp SBC with Quad DP++ and Triple LAN |
| 16GB |
| 1 |
| DDR4 |
| Supports ECC Memory |
|
Linux Windows |
|
AMD Ryzen V-Series |
| V-Series |
| V1404I |
| 1x DDR4 3200MHz SO-DIMM Slot, 16GB |
| AMI |
| TPM 2.0 (Trusted Platform Module) |
|
Linux Windows 10 |
| AMD Radeon Series |
| AMD Radeon Graphics |
| Triple Display Support |
| 4x Display Ports |
| Display Port |
|
Line-Out Mic-In |
| 3x Ethernet Ports |
| RJ45 |
| 3 x GbE LAN [RJ45] |
| GbE |
| 4x USB Ports |
|
Board Connectors Type A |
|
USB2 USB3 |
|
1 x USB 2.0 [Board] 1 x USB 2.0 [Type A] 2 x USB 3.1 Gen 1 [Type A] |
| 1x Serial Ports |
| Board Connectors |
|
RS-232 RS-422 RS-485 |
| 1 x RS232/422/485 [Board] |
| DIO [8-lines] |
| 1x M.2 Expansion Slots |
| 1x M.2 M-Key [PCIe x4] [2242/2280] |
| M-Key |
| PCIe |
|
2242 2280 |
| 1x mPCIe Slots |
| 1 x mPCIe [PCIe/USB] |
|
PCIe USB |
| Full-Size |
| 1x SIM Slots |
|
Optional 4G Modem Optional 5G Modem Optional WiFi/Bluetooth |
|
4G 5G Wireless |
| 2 |
|
M.2 SSD SATA Port |
|
1x M.2 SSD 1x SATA Port |
| NVMe SSD Support |
| 12V DC [4-Pin] |
|
Optional Heat Spreader Optional Heatsink |
|
Heat Spreader Heatsink |
| -30°C to 80°C [-22°F to 176°F] |
| Wide Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 10-90% (Non-condensing) |
|
CE FCC RoHS |
| 0.2 Kg (0.44 Lbs) |
| 146mm x 102mm (5.75" x 4.02") |
| DFI GH551-BC1-V1202B |
| AMD Ryzen V1202B Single Board Computer with 3x DP++ and LVDS |
| 16GB |
| 1 |
| DDR4 |
| Supports ECC Memory |
|
Linux Windows |
|
AMD Ryzen V-Series |
| V-Series |
| V1202B |
| 1x DDR4 3200MHz SO-DIMM Slot, 16GB |
| AMI |
| TPM 2.0 (Trusted Platform Module) |
|
Linux Windows 10 |
| AMD Radeon Series |
| AMD Radeon Graphics |
| Triple Display Support |
|
1x LVDS 3x Display Port |
|
Display Port LVDS |
|
Line-Out Mic-In |
| 3x Ethernet Ports |
| RJ45 |
| 3 x GbE LAN [RJ45] |
| GbE |
| 4x USB Ports |
|
Board Connectors Type A |
|
USB2 USB3 |
|
1 x USB 2.0 [Board] 1 x USB 2.0 [Type A] 2 x USB 3.1 Gen 1 [Type A] |
| 1x Serial Ports |
| Board Connectors |
|
RS-232 RS-422 RS-485 |
| 1 x RS232/422/485 [Board] |
| DIO [8-lines] |
| 1x M.2 Expansion Slots |
| 1x M.2 M-Key [PCIe x4] [2242/2280] |
| M-Key |
| PCIe |
|
2242 2280 |
| 1x mPCIe Slots |
| 1 x mPCIe [PCIe/USB] |
|
PCIe USB |
| Full-Size |
| 1x SIM Slots |
|
Optional 4G Modem Optional 5G Modem Optional WiFi/Bluetooth |
|
4G 5G Wireless |
| 2 |
|
M.2 SSD SATA Port |
|
1x M.2 SSD 1x SATA Port |
| NVMe SSD Support |
| 12V DC [4-Pin] |
|
Optional Heat Spreader Optional Heatsink |
|
Heat Spreader Heatsink |
| -5°C to 65°C [23°F to 149°F] |
| Wide Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 10-90% (Non-condensing) |
|
CE FCC RoHS |
| 0.2 Kg (0.44 Lbs) |
| 146mm x 102mm (5.75" x 4.02") |
| DFI GH551-BC1-V1605B |
| AMD Ryzen V1605B SBC with Quad Display and Triple LAN |
| 16GB |
| 1 |
| DDR4 |
| Supports ECC Memory |
|
Linux Windows |
|
AMD Ryzen V-Series |
| V-Series |
| V1605B |
| 1x DDR4 3200MHz SO-DIMM Slot, 16GB |
| AMI |
| TPM 2.0 (Trusted Platform Module) |
|
Linux Windows 10 |
| AMD Radeon Series |
| AMD Radeon Graphics |
| Triple Display Support |
| 4x Display Ports |
| Display Port |
|
Line-Out Mic-In |
| 3x Ethernet Ports |
| RJ45 |
| 3 x GbE LAN [RJ45] |
| GbE |
| 4x USB Ports |
|
Board Connectors Type A |
|
USB2 USB3 |
|
1 x USB 2.0 [Board] 1 x USB 2.0 [Type A] 2 x USB 3.1 Gen 1 [Type A] |
| 1x Serial Ports |
| Board Connectors |
|
RS-232 RS-422 RS-485 |
| 1 x RS232/422/485 [Board] |
| DIO [8-lines] |
| 1x M.2 Expansion Slots |
| 1x M.2 M-Key [PCIe x4] [2242/2280] |
| M-Key |
| PCIe |
|
2242 2280 |
| 1x mPCIe Slots |
| 1 x mPCIe [PCIe/USB] |
|
PCIe USB |
| Full-Size |
| 1x SIM Slots |
|
Optional 4G Modem Optional 5G Modem Optional WiFi/Bluetooth |
|
4G 5G Wireless |
| 2 |
|
M.2 SSD SATA Port |
|
1x M.2 SSD 1x SATA Port |
| NVMe SSD Support |
| 12V DC [4-Pin] |
|
Optional Heat Spreader Optional Heatsink |
|
Heat Spreader Heatsink |
| -5°C to 65°C [23°F to 149°F] |
| Wide Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 10-90% (Non-condensing) |
|
CE FCC RoHS |
| 0.2 Kg (0.44 Lbs) |
| 146mm x 102mm (5.75" x 4.02") |
