Arestech PPC-N158
Things Embedded are an official Arestech UK distributor and can supply the PPC-N158 fully configured and imaged.
Available in 2 Variants
| Overview |
|---|
| Brand & Model |
| Sub Categories |
| Display |
| Display Size |
| Display |
| Display Resolution |
| Touch Technology |
| Touch Controller |
| Brightness |
| Brightness |
| Viewing Angle |
| Aspect Ratio |
| Format |
| Contrast |
| Performance |
| Memory Capacity |
| Memory Slots |
| Memory Type |
| Operating Software |
| Processor |
| Processor Series |
| Processor Models |
| Memory |
| BIOS |
| Operating System |
| Graphics |
| Display Outputs |
| Display Port Type |
| Audio |
| Codec |
| Interface |
| I/O |
| Ethernet |
| Ethernet Connector Type |
| Ethernet Speed |
| LAN Controllers |
| USB |
| USB Connector Type |
| USB Generation |
| Serial |
| Serial Connector Type |
| Serial Protocol |
| Digital I/O |
| Expansion |
| M.2 |
| M.2 Key Support |
| M.2 Signal Support |
| M.2 Slot Size |
| mPCIe |
| mPCIe Support |
| mPCIe Slot Size |
| SIM Slots |
| Wireless Connectivity |
| Connectivity |
| Storage |
| Number of Storage Bays |
| Storage Interface |
| Storage |
| Power |
| Power Input |
| Power Support Modes |
| Environmental Conditions |
| Operating Temperature |
| Operating Temperature |
| Storage Temperature |
| Humidity |
| Ingress Protection |
| Ingress Protection |
| Certification |
| Mechanical Properties |
| Weight |
| Dimensions |
| Arestech PPC-N158R |
| 15" Intel Core i5-8265U IP66 Whiskey Lake Panel PC with Resistive Touch |
| Arestech PPC-N Series |
| 15" |
| 15"[4:3, 1024 x 768, XGA] |
| XGA |
| Resistive |
| 5-Wire Resistive Touch |
| 300 Nits |
| 300 |
| Wide Viewing Angle |
| 160° Horizontal, 160° Vertical |
| 4:3 |
| Standard |
| 600:1 |
| 32GB |
| 2 |
| DDR4 |
|
Linux Windows |
|
8th Gen Whiskey Lake Intel Core |
| 8th Gen Whiskey Lake |
| i5-8265U |
| 2x DDR4 2133MHz SO-DIMM Slots, 32GB |
| UEFI |
|
Linux Windows 10 |
| 1x HDMI |
| HDMI |
| Realtek HD Audio |
|
Line-Out Mic-In |
| 2x Ethernet Ports |
| RJ45 |
| 2 x GbE LAN [RJ45] |
| GbE |
|
Intel i211AT Intel i219V |
| 4x USB Ports |
| Type A |
| USB3 |
| 4 x USB 3.1 Gen 1 [Type A] |
| 4x Serial Ports |
| DB9 |
|
RS-232 RS-422 RS-485 |
|
1 x RS232/422/485 [DB9] 3 x RS232 [DB9] |
| DIO [8-lines] |
| 2x M.2 Expansion Slots |
|
1x M.2 A/E-Key [SATA] [2230] 1x M.2 B/M-Key [PCIe x4/SATA] [2280] |
|
A-Key B-Key E-Key M-Key |
|
PCIe SATA USB |
|
2230 2280 |
| 1x mPCIe Slots |
| 1 x mPCIe [PCIe/USB] |
|
PCIe USB |
| Full-Size |
| 1x SIM Slots |
|
Optional 4G Modem Optional WiFi/Bluetooth |
|
4G Wireless |
| 2 |
|
2.5" HDD/SSD M.2 SSD |
|
1x 2.5" HDD/SSD 1x M.2 SSD |
| 9-36V DC Input, Terminal Block |
|
AT: PWR on Input ATX: Press Button to Power |
| -20°C to 60°C [-4°F to 147°F] |
| Wide Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 5% - 95% (Non-condensing) |
| Front IP66 |
| Front IP66 [Dustproof, Protection against powerful water jets spraying from the front side] |
|
CE FCC |
| 4.2 Kg (9.24 Lbs) |
| 386mm x 316mm x 69mm (15.2" x 12.44" x 2.72") |
| Arestech PPC-N158P |
| 15" Intel Core i5-8265U IP66 Whiskey Lake Panel PC with PCAP Touch |
| Arestech PPC-N Series |
| 15" |
| 15"[4:3, 1024 x 768, XGA] |
| XGA |
| PCAP |
| Projective Capacitive Touch |
| 300 Nits |
| 300 |
| Wide Viewing Angle |
| 160° Horizontal, 160° Vertical |
| 4:3 |
| Standard |
| 600:1 |
| 32GB |
| 2 |
| DDR4 |
|
Linux Windows |
|
8th Gen Whiskey Lake Intel Core |
| 8th Gen Whiskey Lake |
| i5-8265U |
| 2x DDR4 2133MHz SO-DIMM Slots, 32GB |
| UEFI |
|
Linux Windows 10 |
| 1x HDMI |
| HDMI |
| Realtek HD Audio |
|
Line-Out Mic-In |
| 2x Ethernet Ports |
| RJ45 |
| 2 x GbE LAN [RJ45] |
| GbE |
|
Intel i211AT Intel i219V |
| 4x USB Ports |
| Type A |
| USB3 |
| 4 x USB 3.1 Gen 1 [Type A] |
| 4x Serial Ports |
| DB9 |
|
RS-232 RS-422 RS-485 |
|
1 x RS232/422/485 [DB9] 3 x RS232 [DB9] |
| DIO [8-lines] |
| 2x M.2 Expansion Slots |
|
1x M.2 A/E-Key [SATA] [2230] 1x M.2 B/M-Key [PCIe x4/SATA] [2280] |
|
A-Key B-Key E-Key M-Key |
|
PCIe SATA USB |
|
2230 2280 |
| 1x mPCIe Slots |
| 1 x mPCIe [PCIe/USB] |
|
PCIe USB |
| Full-Size |
| 1x SIM Slots |
|
Optional 4G Modem Optional WiFi/Bluetooth |
|
4G Wireless |
| 2 |
|
2.5" HDD/SSD M.2 SSD |
|
1x 2.5" HDD/SSD 1x M.2 SSD |
| 9-36V DC Input, Terminal Block |
|
AT: PWR on Input ATX: Press Button to Power |
| -20°C to 60°C [-4°F to 147°F] |
| Wide Temperature |
| -40°C to 85°C [-40°F to 185°F] |
| 5% - 95% (Non-condensing) |
| Front IP66 |
| Front IP66 [Dustproof, Protection against powerful water jets spraying from the front side] |
|
CE FCC |
| 4.2 Kg (9.24 Lbs) |
| 386mm x 316mm x 69mm (15.2" x 12.44" x 2.72") |
